TD Series
is an user-friendly, highly regarded interactive equipment. It integrates the advantages of touch screen, computer, multimedia, sound, internet, industrial, mechanical manufacturing streamline design etc. To achieve the simple and practical interactive function, TD series equipped with pure flat structure, high performance in touching for display or query.
Features
1. Capacitive Touchscreen:10-point capacitive touch screen, 5 ms response.
2. Durable material：Aluminum alloy frame & sheet metal shell, corrosion and oxidation resistance.
3. Optional color for white-silver, black, black-silver.
4. Waterproof IP65 at the surface, slim & pure flat structure.
5. System compatible with touchscreen monitor/Andorid or X86 touch screen AIO PC.
6. Flexible customizatoin for USB and COM por, color, logo, camera, card reader, fingerprint, PoE power supply.
7. Plug and play, no any driver needed.
8. With good anti-interference to get stable operatoin guarantee.
Touch Screen Parameters
|
Touch Screen:
|
Capacitive Touch
|
|
Response Time:
|
5ms
|
|
Touch Points:
|
10 points Multi-touch
|
|
Touch Materials:
|
Finger, Stylus
|
|
Scanning Frequency:
|
200 Hz
|
|
Scanning Accuracy:
|
4096x4096
|
|
Communication Mode:
|
Full Speed USB 2.0/3.0
|
|
MTBF:
|
5000 Million Times
|
|
Operating Current:
|
180Ma/DC+5V
|
|
Anti-light Interference:
|
Under Sunlight and Other Lights
|
|
Touch Data Output:
|
Coordinate Output
|
|
Hardness:
|
Mohs 7 Explision-proof Tempered Glass
|
|
Operating System:
|
Windows XP/7/8/10/Linux/MAC/Android
|
|
Driver:
|
Free Driver, Plug and Play
|
LED Screen Parameters
|
Screen Type:
|
LED Backlight, A-type
|
|
Refresh Frequency:
|
60Hz
|
|
Viewing Angle:
|
89°/89°/89°/89° (R/L/U/D)
|
|
MTBF:
|
50,000 hrs
|
Power Supply Parameters
|
Input Power:
|
110-240V AC 50/60Hz
|
|
Power Consumption:
|
60W or 120 ~ 280W
|
|
Standby Power Consumption:
|
1W
|
Working Environment
|
Operating Temperature:
|
-10°C ~ 60°C
|
|
Operating Humidity:
|
10% ~ 80%
|
|
Storage Temperature:
|
-20°C ~ 80°C
|
|
Storage Humidity:
|
5% ~ 90%
|
Computer Configuration
Program: |
Touch Monitor
|
Android
|
X86 Standard
|
X86 Deluxe
|
|
Chip:
|
Industrial Driver Board
|
RK3368/RK33288/RK3399
|
Intel Celeron Quad Core J1900
|
Intel Core i3/i5/i7
|
|
Memory:
|
-
|
2GB/4GB
|
2GB/4GB/8GB/16GB
|
|
Storage:
|
-
|
8GB/16GB/32GB
|
SSD 32GB/64GB/128GB/256GB/512GB, HDD 500GB/1T
|
|
Graphics:
|
-
|
Android HD
|
Core Graphics
|
|
Resolution:
|
-
|
720P/1080P
|
|
OS:
|
-
|
Android 7.1
|
Windows XP/7/8/10/Linux/MAC
|
|
Network:
|
-
|
Gigabit Network Card; Wireless Module 802.11a/b/g/n
|
