Key Feature
Product Name: | 10'' IP65 Rugged Tablet PC | CPU: | MediaTek MT6735 ARM® 4x Cortex® A53 1.3GHz |
---|---|---|---|
RAM: | 3G | Flash: | 32GB |
Touchscreen Type: | 10 Points Capacitive Touch | Resolution: | 1920x1200 |
Aspect Ratio: | 16:10 | IP Grade: | FULL IP65 |
Material: | ABS/PC/Rubber TPU/Aluminum | Battery: | 10500mAh |
1. 10.1 inch android 7.0 rugged tablet
2. RAM/ROM 3GB/32GB
3. Screen Resolution 1200*1920
4. 4G LTE/WIFI/GPS/BT
5. Hot swap battery
6. Support RJ45, RS232, USB 2.0, Micro USB
7. Back pogo pin for extend, bottom pogopin for docking station
8. Support original handwriting stylus (optional)
****Standard color is black, other colors MOQ: 200 pcs
Model: UMST-11A | |||||
OS | Android 7.0 | ||||
CPU | MediaTek MT6735 ARM® 4x Cortex® A53 1.3GHz | ||||
RAM/ROM | 3GB/32GB | ||||
LCD | 10.1 inch1920*1200 | 500 nits sunshine readable | |||
Touch screen | 10 point touch, support stylus & thin glove |
||||
Camera | 5M/13M, flash | ||||
Power and battery |
battery
total capacity 10500mAh play video 8 hours, working 10 hours charging 4 hours |
8400mAh,hotswap,
2100mAh backup power 3.8V 3A imput, support hotswap play video 8 hours, working 10 hours charging 4 hours. |
|||
3.5*1.35mm, 5V 3A DC input | Magnetic charger | ||||
WWAN | 4G LTE, 3G WCDMA, GSM |
4G
Fre: FDD: B1,B2, B3,B5, B7, B8, B12, B20 TDD: B38,B39,B40,B41 B34 WCDMA:B1, B8 TD-SCDMA: B34, B39 GSM/GPRS/EDGE |
|||
GPS | baidou,GPS, glonass | ||||
Wi-Fi | 802.11a b c, g,n wireless internet Wireless AP ( Mobile AP )2.4G, 5G | ||||
BLUETOOTH | 4.0 version | ||||
NFC | 13.56 MHz, distance 5cm or above | ||||
Speaker | 1.5 watt | ||||
Sensor | 1.
light sensor 2. gravity 3. acceleration 4. compass 5. baroreceptor |
||||
Size | 275*178*18mm | ||||
Multi-media (Hardware decoding) |
Photo Viewer | BMP, JPG, GIF, PNG | |||
Video Format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) | ||||
Audio Format | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) | ||||
Language | multi language | ||||
Interface in/out port |
1.
normal USB*1 2. Micro USB*1 3. RJ45*1 4. bottom pogopin*1, USB and serial 5. back pogopin*1 6. DC*1 3.5*1.35 7. microphone+earphone 8. mini HDMI 9.RS232*1 |
||||
Pogopin definition |
1.16pin
back of cover, include (1USB, 1 RS232, 1 UART, 3.3V, 5V OUT) 2. 8pin in bottom; (1USB, 1 RS232, 1 UART, ) VESA hole 75*75mm or 90*90mm |
||||
Casing material | ABS/PC/Rubber TPU/Aluminum | ||||
Button | V+ -, Power, P, F, H | ||||
2D barcode module | honeywell N3680 | ||||
Fingerprint module | LD-8800-M | ||||
Accessories |
1.
USB cable 2. charger 3. handstrap 4. car holder 5. docking station 6. car charger 7. white box, no logo |
||||
Proof rate |
1.
water proof IP65 2. Drapping proof 1.2 meter |
||||
Certification |
1.
810G 2. CE,FCC |
||||
Temperature |
1.
storate temperature -25 to 80 degree 2. operation temperature -20 to 60 degree |
Application
Field service and utility
Law enforcement / Police officer
Geographic Information System
Tracking- monitoring
Inventory
Application
Industrial automation
Self-service payment machine
Hotel check-in kiosk
Smart Home
Medical testing equipment
Egas Printer box
Customer Feedback Kiosk
Agriculture automation
Monitoring center
